Aluminum single-panel curtain wall

I. Product Overview

Aluminum single-panel curtain wall is a building exterior wall decoration material made of high-strength aluminum alloy panels through bending, welding, and spraying processes. It boasts advantages such as lightweight and high strength, strong weather resistance, rich colors, and flexible shapes, making it a commonly used exterior curtain wall system for modern high-rise buildings, commercial complexes, and urban landmarks.

II. Product Structure

A standard aluminum single-panel consists of three parts:

Front Panel: Commonly made of 1100/3003/5052 aluminum alloy

Stiffeners: Enhance structural strength and prevent deformation

Mounting Flanges: Connected and fixed to the main structure with screws

Surface treatments include fluorocarbon spraying (PVDF), electrostatic powder coating, anodizing, and wood grain transfer.

III. Key Features

1. Superior Weather Resistance

PVDF fluorocarbon coating ensures no fading or chalking for 20-25 years.

Excellent corrosion resistance, acid rain resistance, and UV resistance.

2. Lightweight and High Strength

Density is only 1/3 that of steel.

Excellent compressive strength, wind resistance, and earthquake resistance.

3. Flexible Shaping and Processing

Can achieve various shapes including flat, curved, angled, irregular, perforated, and hollowed-out designs.

Suitable for complex building facade designs.

4. Rich Colors

Available in metallic colors, wood grain, stone grain, ceramic colors, 3D textures, etc.

Uniform surface and high-end texture.

5. Convenient Installation and Maintenance

Modular installation, short construction period.

Simple cleaning is all that’s needed for maintenance.

6. Environmentally Friendly, Fireproof, and Moisture-proof

Belongs to a metallic material and is fully recyclable.

Fire rating A, safe and reliable.

Moisture-resistant, non-deformable, and mildew-resistant.

IV. Technical Specifications
Item Specifications

Material: 1100 / 3003 / 5052 Aluminum Alloy

Thickness: 1.5mm / 2.0mm / 2.5mm / 3.0mm (Customizable)

Standard Sizes: 600×600mm / 800×1200mm / 1200×2400mm (Customizable according to drawings)

Surface Treatment: PVDF Fluorocarbon Coating / Powder Coating / Anodizing / Wood Grain Transfer

Coating Colors: RAL Color Chart / Powder Color Chart / Custom Colors

Processing Techniques: Punching, Bending, Welding, Carving, Grooving, Arc Shaping

Fire Rating: Class A

Weathering Life: 20–25 years

V. Application Areas

Shopping Malls

Office Buildings

Landmark Buildings

Airports, High-Speed ​​Rail Stations, Subway Stations Hubs

Public Buildings (Government Buildings, Hospitals, Schools)

Hotels & Convention Centers

VI. Customization Options

Processing based on provided drawings / Custom production according to drawings

Special shapes (curved panels, irregularly shaped panels, corner panels)

Custom wood grain/stone grain/metal grain/special colors

Perforated/cutout patterns (customizable lighting effects)

Customized stiffener layout and panel size

Glossy/matte/metallic finish options

VII. Installation System

A variety of standard curtain wall system structures are available:

Horizontal and vertical keel dry-hanging system

Back-bolted system

Closed-fitting/ventilated curtain wall structure

Waterproof and sealing structure

Structural solutions and installation guidance are available.

VIII. Packaging & Delivery

Single-piece protective film

Corner protection at all four corners

Foam + wooden crate/pallet packaging

Scratch-resistant and collision-resistant transportation solutions
